| 원래 장소: | 중국 |
|---|---|
| 브랜드 이름: | FANRYN |
| 포장 세부 사항: | 비닐 봉지 |
| 배달 시간: | 근무일 기준 10일 |
| 지불 조건: | 티/티 |
| 재료: | 미네랄 울 | 용법: | 건물 및 산업용 단열재 |
|---|---|---|---|
| 밀도: | 10-200 kg/m3 | 내화학성: | 대부분의 화학 물질에 내성이 있습니다 |
| 흡수: | 최대 1.0 NRC | 절연 유형: | 단열 |
| 설치방법: | 느슨한 채우기, 배트 또는 보드 | 열전도율: | 0.035-0.045 w/mk |
| 환경 영향: | 천연 및 재활용 재료로 제작되었습니다 | 수분 흡수: | 1% 미만 |
| 압축 강도: | 10-30kPa | 온도 범위: | -50°C ~ 650°C |
| 내화성: | 클래스 A1 | 두께: | 25-200 mm |
| 강조하다: | mineral wool pipe insulation,thermal insulation for pipes,comprehensive size pipe insulation |
||
Efficient insulation starts with a perfect fit. FANRYN Rock Wool Pipes are precision-manufactured to cover an extensive range of standard pipe diameters, from small 1/2" (22mm) service lines to large 24" (610mm) main conduits. Our product matrix ensures that for nearly every pipe in your plant, factory, or building, there is a correctly sized rock wool section available.
This precise fit is crucial for performance. It minimizes heat loss or gain by eliminating gaps and cold bridges, ensuring the thermal conductivity of ≤0.044 W/mK is consistently achieved across the entire system. Furthermore, our strict quality control guarantees an eccentricity of ≤5mm, meaning the insulation thickness is uniform around the entire pipe circumference. This prevents weak spots and ensures uniform thermal and acoustic performance, leading to optimal energy savings and consistent condensation control.
|
Properties |
Specifications |
Standards |
|
Density Tolerance |
±15% |
GB/T 19686-2005 |
|
Fire Performance |
Non-Combustible |
GB/T 5464-1999 |
|
|
Reaction to fire Class A1 |
GB/T 8624-2006 |
|
Thermal Conductivity (W/mK, at70±5℃) |
≤0.044 |
GB/T 10295 |
|
Fiber Diameter |
7(+/-1)um |
GB/T 5480. 4 |
|
Shot Content (shot size＞0.25mm) |
≤12% |
|
|
Eccentricity of Pipe shell |
≤5mm |
|
|
DIA |
Thickness (mm) |
|||||||||||
|
inch |
mm |
25 |
30 |
40 |
50 |
60 |
70 |
80 |
90 |
100 |
120 |
150 |
|
1/2’’ |
22 |
● |
● |
|
● |
|
|
|
|
|
|
|
|
3/4’’ |
27 |
● |
● |
● |
● |
● |
● |
● |
|
|
|
|
|
1’’ |
34 |
● |
● |
● |
● |
● |
● |
● |
|
|
|
|
|
1-1/4’’ |
43 |
● |
● |
● |
● |
● |
● |
● |
● |
● |
|
|
|
1-1/2’’ |
48 |
● |
● |
● |
● |
● |
● |
● |
● |
● |
|
|
|
2’’ |
60 |
● |
● |
● |
● |
● |
● |
● |
● |
● |
|
|
|
2-1/2’’ |
76 |
● |
● |
● |
● |
● |
● |
● |
● |
● |
|
|
|
3’’ |
89 |
● |
● |
● |
● |
● |
● |
● |
● |
● |
|
|
|
3-1/2’’ |
108 |
● |
● |
● |
● |
● |
● |
● |
● |
● |
|
|
|
4’’ |
114 |
● |
● |
● |
● |
● |
● |
● |
● |
● |
● |
|
|
5’’ |
140 |
|
● |
● |
● |
● |
● |
● |
● |
● |
● |
● |
|
6’’ |
169 |
|
● |
● |
● |
● |
● |
● |
● |
● |
● |
● |
|
8’’ |
219 |
|
|
● |
● |
● |
● |
● |
● |
● |
● |
● |
|
10’’ |
273 |
|
|
● |
● |
● |
● |
● |
● |
● |
● |
● |
|
12’’ |
325 |
|
|
● |
● |
● |
● |
● |
● |
● |
● |
● |
|
14’’ |
356 |
|
|
|
● |
● |
● |
● |
● |
● |
● |
● |
|
15’’ |
381 |
|
|
|
● |
● |
● |
● |
● |
● |
● |
● |
|
16’’ |
406 |
|
|
|
● |
● |
● |
● |
● |
● |
● |
● |
|
18’’ |
456 |
|
|
|
● |
● |
● |
● |
● |
● |
● |
● |
|
19’’ |
483 |
|
|
|
|
|
● |
● |
● |
● |
● |
● |
|
20’’ |
508 |
|
|
|
|
|
● |
● |
● |
● |
● |
● |
|
22’’ |
558 |
|
|
|
|
|
|
● |
● |
● |
● |
● |
|
24’’ |
610 |
|
|
|
|
|
|
● |
● |
● |
● |
● |
Extensive Diameter Range: Covers from 22mm to 610mm (1/2" to 24").
Multiple Thickness Options: Available in thicknesses from 25mm to 150mm to meet specific thermal requirements.
Low Eccentricity (≤5mm): Ensures uniform thickness around the pipe for consistent, reliable performance.
Insulation and fireproof of huge projects like power plant, oil depot and petrochemical works.
Q1: How to guarantee the quality of the products?
A1: Our experienced QC team will inspect product's quality in every process
Q2: How to pack exported goods?
A2: Plastic bag (Standard Export Packing).
Q3: what is your lead time for one 40HC container order?
A3: Usual 15-20 work days after placing order.
Q4: What is your advantage on rock wool pipe?
A4: Special product with special specification can be made to order.
Q5: About the after-sale service, how to solve the problems occurred of your overseas customer in time?
A5: The warranty of our products is one year. If our products or packing exist quality problem, we will replace or compensate accordingly.
